3M Novec 7100 Engineered Fluid

3M Novec 7100 Engineered Fluid

3M Novec 7100 is a high-performance engineered fluid designed for various industries, featuring a low boiling point, excellent environmental properties, and high safety without posing any health risks to humans. It is suitable for a wide range of applications, including heat transfer, cleaning, lubrication, and dilution.

Developed based on 3M's proprietary **Hydrofluoroether** chemical technology, this product has low surface tension and viscosity, with a greater penetrating power than traditional cleaning solvents. It delivers excellent cleaning performance for both metal and non-metal components, making it ideal for precision cleaning of electronic components, optical devices, and semiconductor equipment.

Product Specifications

3M Novec 7100 Engineered Fluid

3M Novec Electronic Fluids 7100

Pound

Kilogram

Gallon

Liter

12lb

5.4kg

1gal

3.79L

33lb

15kg

3.25gal

12.3L

600lb

272.1kg

55gal

208.2L


產品規格

Global Warming Potential, GWP
297 (100 yr ITH)
Global Warming Potential (GWP) Range
Low
Net Weight (Imperial)
12 lb, 33 lb, 600 lb
Overall Height (Imperial)
17 inches, 35 inches, 9.5 inches
Overall Height (Metric)
24.13 cm, 43.18 cm, 88.9 cm
Overall Length (Imperial)
11.5 inches, 23.5 inches, 9.56 inches
Overall Length (Metric)
24.29 cm, 29.21 cm, 59.69 cm
Overall Width (Imperial)
11.5 inches, 23.5 inches, 9.56 inches
Overall Width (Metric)
24.3 cm, 29.2 cm, 59.7 cm
Volume (Imperial)
1 gal, 3.25 gal, 55 gal
Dielectric Strength
>25 (0.1" gap, kV)

It can substitute the existing solvent.

CFCs

Fluorine-based lubricants and dispersions.

Fluorinated Lubricants, PTFE

Brand

Novec™
Unit (liter)
3.79 L12.3 L, 208.2 L

Plastic elastomer compatibility

Excellent

Application areas

Carrier solvent, file storage, heat transfer, Organic Rankine Cycle (ORC), oxygen supply system cleaning, precision cleaning, biological sample preservation.

Maximum operating temperature

<150 °C
材質相容性

ABS/Polycarbonate, Acrylic, Ceramic, Metal, Plastic, Organic Silicone, Solvent-resistant plastics.

Solubility of fluorocarbon compounds

High

Boiling point range

50 °C - 99 °C

Product range

Novec 7100

Product category

Spray, carrier solvent and lubricant deposition diluent, carrier solvent, heat transfer, data center immersion cooling fluid, precision cleaning, solvent-based cleaners and vapor degreasers.

Solubility of hydrocarbons

Medium

Color

Transparent hook
